| outshell structure | ||
| 1.The shell material is fully galvanized steel plate making cabinet, the outer surface is imported metal paint, anti-magnetic, anti-static, imported waterproof material, the whole machine adopts IP55 waterproof, outdoor all-weather waterproof and dustproof, anti-theft, explosion-proof design; 2.Strict electrical protection: leakage, overload, overvoltage protection, lightning protection device, overtemperature protection, etc.; 3.Sound: using dual channel, stereo surround power amplifier system, output power 8 euro 210W; 4.Working environment design standard + 110°~ -50°, cooling using stable and reliable air cooling structure heat dissipation and aluminum military grade heat dissipation substrate; 5.Steened glass: 6mm AR tempered laminated glass; 6.Each system of the whole machine adopts the modular design principle, sustainability, maintainability design; 7.Light sensing system is superior: environment brightness automatic adjustment control anti-glare, to meet the strong direct sunlight environment clear image display; |
||
| Key Features | ||
| 1.Bright LED backlight LCD screen, the brightness reaches 1800 nits, and it is still clearly visible in the sunlight environment; 2.Unique liquid crystal substrate width and temperature treatment can reach-50℃ -110 degrees Celsius, low temperature environment fast start and clear image display; 3.Real bright and bright colors display, up to 2160 x3840 resolution; 4.Outdoor rainproof type heat resistance metal shell, as well as the waterproof and dustproof shell structure in the outdoor storm environment; 5.Built-in stand-alone (network) player board, industrial control computer (optional), interactive multi-touch (optional); 6.Optional function Built-in RFID / NFC Reader / POS Built-in HD Camera Built-in thermal printer 80mm Built-in QR code scanner Upgrade to i3, i5 or i7 Processor |
| Specifications | ||
| LCD Panel | Panel type | 43”LED Panel |
| Displays the size | 943×531mm(W*H) | |
| Show the proportion | 16:09 | |
| Backlit type | Patent LED backlight modular component + constant current source driver component | |
| resolution ratio | 1080*1920 | |
| Show color | 16.7M | |
| luminance | 1800cd/m2Meet the strong direct sunlight environment of the clear image display | |
| contrast ratio | 3500:01:00 | |
| Visual Angle | 178°(H) / 178°(V) | |
| response time | 5ms | |
| Color system | PAL/NTSC/SECAM | |
| life length | For 60,000 hours | |
| PC Part | CPU | The Cortex-A7 architecture, with a main frequency of 1.2G |
| internal storage | DDR3 1G | |
| Built-in memory | Up to 32GB of TF card expansion support | |
| Decoding resolution | The maximum support is 1080P | |
| operating system | Android 7.1.1 | |
| Network support | 3G / 4G wide area network, Ethernet, support for WiFi, wireless peripheral extension | |
| Video play | Support for AVI (H.264、DIVX 、DIVX 、XVID ）, rm ，rmvb ， MKV （H.264、DIVX 、DIVX 、XVID ），WMV ，MOV ，MP4（.H.264, MPEG, DIVX, XVID), DAT (VCD format), VOB (DVD format), PMP, MPEG,.MPG,， FLV （H.263，H.264), ASF, TS, TP, 3GP, MPG and other over 30 formats | |
| picture format | Support for BMP, JPEG, PNG, and GIF | |
| The USB2.0 interface | 2 USB HOST standard interfaces and 2 USB extension interfaces | |
| system upgrade | Supports USB upgrade, SD card upgrade, remote upgrade | |
| Battery | Battery technology | Blade battery, long use time, stable performance |
| charging interval | Charge for 7 hours | |
| operate time | Work 14 hours | |
| battery capacity | 50000 mAh | |
| input voltage | 24V | |
| working environment | working temperature | -50℃～110℃ |
| Storage temperature | -45℃～80℃ | |
| Working humidity | 10%～90% | |
| Store humidity | 10%～90% | |
| power consumption | power input | AC100V～240V |
| Power power consumption | ≤100W | |
| Standby power consumption | ≤3W | |
| color | Appearance color | Silver, gray, white, black, red |
| material | Case material | Galvanized steel plate + outdoor special baking paint |
| certification | product certification | ISO9001,3C,FCC,UL |
| Size and weight | net weight | 40Kg |
| rough weight | 48Kg | |
| product size | 1236mm*148mm*588mm | |
| packing measurement | 1350mm*300mm*700mm | |
